This industrial broom design from Erskine offers a heavy-duty frame, oversized bearing, and larger motor drive block. The strong and simple-to-use parking stands need no tools and have no pins that can get lost. The floating tilt follows the contours of uneven surfaces for better bristle contact and even bristle wear. Available in three widths (see below).
Features
- 8° floating tilt allows broom to follow ground contour. This helps prevent bristle coning when angled,
- Oversized 4” bearing on arbor,
- Stronger reinforced frame,
- Handles on bearing help with arbor change,
- Handles on motor can help with bearing change and help protect motor,
- Easy flip down stands require no tools and no pins,
- Angle side to side 30 degrees,
- Larger 3” hex drive helps with longevity.
SPECIFICATIONS
| Model | 720HD / 720HDX / 720HDXL | 840HD / 840HDX / 840HDXL | 960HD / 960HDX / 960HDXL |
|---|---|---|---|
| Width | 72” | 84” | 96” |
| Width Fully Angled | 62” @ 30° | 72.5” @ 30° | 83” @ 30° |
| Broom Angling | Manual 30° / Hyd 30° / Hyd 30° | Manual 30° / Hyd 30° / Hyd 30° | Manual 30° / Hyd 30° / Hyd 30° |
| Drive System | Hydraulic Motor Direct-Drive | Hydraulic Motor Direct-Drive | Hydraulic Motor Direct-Drive |
| Skid Steer Flow Range | 13-24 GPM | 13-24 GPM | 13-24 GPM |
| Wafer Diameter | 32” | 32” | 32” |
| Wafer Sections (number) | 38 | 44 | 50 |
| Mounting Plate | Universal | Universal | Universal |
| Weight | 850 lb. | 900 lb. | 950 lb. |
| Reversible Valve Block | Included w/XL model | Included w/XL model | Included w/XL model |
| Options | |||
| Pistol Grip Control Harness* | |||
| Loader Specific Wire Harness* | |||
| Factory Installed Couplers | |||
| *Applies to Hydraulic Models Only | |||
