| Model | 48” | 60” |
|---|---|---|
| Part Number | 900708 | 900709 |
| Operating Weight | 505 lb. | 545 lb. |
| Frame Width | 45.5” | 45.5” |
| Frame Width with Steps | 54” | 54” |
| Fork Length | 48” | 60” |
| Overall Height | 35.5” | 35.5” |
| Overall Length | 59.25” | 71.25” |
| Capacity @ 24” Load Center | 5,500 lb. | 5,500 lb. |
| Minimum Fork Width | 8.5” | 8.5” |
| Maximum Fork Width | 42.75” | 42.75” |
- Forks move in and out simultaneously
- Bolt-on steps assist in getting in and out of skid steer
- 48” and 60” models available
