Erskine Pavement Saw – 915PS -925PS – 945PS

The Pavement Saw is a cost effective alternative to a more cumbersome self-propelled saw unit. Available now from Accudraulics.

EAPVS-action-guide-marker-300x200.jpg  EAPVS-studio-main-view-300x200.jpg EAPVS-action-left-view-300x200.jpg

The Erskine pavement saw is a cost-effective alternative to a more cumbersome self-propelled saw unit. With its powerful planetary/motor combination, the 9” cutter wheel depth is ideal for cutting patches, expansion joints and pavement cuts for utility and traffic loops. The planetary drive motor and tungsten carbide teeth eat through asphalt and hard surfaces with ease. The patented electro-hydraulic side-shift enables the Razor Tooth to cut close to walls, curbs and other fixed objects.

brochure hydraulic tool manual icon book hydraulic tools and attachments

Features

  • Guide arm for straight & accurate cuts,
  • Hydraulic depth control maintains a consistent depth of cut,
  • Planetary drive coupled with high flow hydraulics generates high torque for cutting,
  • Durable heavy-duty cast rollers,
  • Adaptable to all skid steer loaders with high flow hydraulic capacity and replaces more cumbersome self-propelled saw units,
  • 9″ cutting depth is ideal for cutting patches and expansion joints and making pavement cuts for utility lines and traffic loops,
  • Electro-hydraulic side-shift enables the saw to cut close to walls, curbs, and fixed objects,
  • Built-in shroud retracts as cutting depth increases.
Model 915PS 925PS 945PS
Part Number 901196 901182 901183
Motor Specifications
Minimum Flow Rate 22 GPM 25 GPM 25 GPM
Maximum Flow Rate 40 GPM 40 GPM 40 GPM
Maximum Speed 180 RPM 180 RPM 180 RPM
Minimum Operating Pressure 2,800 psi 2,800 psi 3,000 psi
Maximum Pressure 5,500 psi 5,500 psi 5,500 psi
Maximum Power Output 60 60 60
Maximum Torque 5,000 lb-ft 5,000 lb-ft 5,000 lb-ft
Saw Specifications
Hydraulic Flow Classification High Flow High Flow High Flow
Number of Teeth 36 28 28
Width of Cut 1.5″ 2.5″ 4.5″
Depth of Cut 9” 9” 9”
Depth Control Hydraulic Hydraulic Hydraulic
Side-Shift Distance 24″ 24″ 24″
Side-Shift Control Hydraulic Hydraulic Hydraulic
Overall Width 67″ 67″ 67″
Overall Length 59″ 59″ 59″
Overall Height 40″ 40″ 40″
Overall Weight 1,300 lb. 1,335 lb. 1,365 lb.
Options
Pistol Grip Control Harness
Loader Specific Wire Harness
Factory Installed Case Drain Coupler
Factory Installed Couplers
Factory Installed High Flow Couplers
