LaBounty Mobile Shears are engineered to maximize performance, longevity and safety with significantly reduced maintenance time. LaBounty has mobile shears for scrap metal processing, demolition and road/bridge reconstruction, building demolition, and wood demolition and recycling.
FEATURES
- Patented Reversible Saber Tip is less maintenance and more operating time,
- Patented LaBounty built reversed, large bore, forged cylinder rods and seal design leads to longer seal life and higher operation PSI,
- Dual Guide Slide Puck system keeps the jaw aligned and reduces jamming,
- Rotating models offer 360 degree rotating for ease of use,
- Speed valves provide faster cycle times .
Looking for a shear small enough for interior processing of metal yet extremely powerful? The MSD 7R Mobile Shear extends the usefulness of your bobcat or skid steer.
Check out this video of a LaBounty shear in use at our client’s facility: Interlake Salvage and Recycling in Stonewall, Manitoba.
Watch the video below on how to maintain your shears’ blades.
SPECIFICATIONS
| IMPERIAL | EXCAVATOR WEIGHT 2ND MEMBER (LBS) | EXCAVATOR WEIGHT 3RD MEMBER (LBS) | ATTACHMENT WEIGHT (LBS) | JAW OPENING (IN) | JAW DEPTH (IN) | REACH (2ND MEMBER) (FT) |
|---|---|---|---|---|---|---|
| MSD 7R | 7,500 | 15,000 | 1,100 | 10 | 11 | 5′ |
| MSD 800 | 15,000 | 20,000 | 2,735 | 15 | 17 | 7’3″ |
| MSD 800R | 18,000 | 26,000 | 2,250 | 15 | 17 | 7’3″ |
| MSD 1000 | 20,000 | 35,000 | 4,200 | 19 | 20 | 5’11” |
| MSD 1000R | 23,000 | 40,000 | 4,400 | 19 | 20 | 8’6″ |
| MSD 1500 | 27,000 | 55,000 | 6,600 | 22 | 25 | 6’9″ |
| MSD 1500R | 40,000 | 66,000 | 7,000 | 22 | 25 | 9’3″ |
| MSD 2000 | 42,000 | 70,000 | 8,850 | 28 | 29 | 8’3″ |
| MSD 2000R | 50,000 | 90,000 | 10,200 | 28 | 29 | 11’0″ |
| MSD 2250 | 44,000 | 88,000 | 10,500 | 30 | 30 | 8’0″ |
| MSD 2250R | 55,000 | 110,000 | 12,500 | 30 | 30 | 11’9″ |
| MSD 2500 | 50,000 | 90,000 | 12,000 | 32 | 34 | 8’9″ |
| MSD 2500R | 70,000 | 110,000 | 14,600 | 32 | 34 | 12’6″ |
| MSD 3000 | 70,000 | 144,000 | 13,300 | 35 | 38 | 9’10” |
| MSD 3000R | 95,000 | 160,000 | 17,000 | 35 | 38 | 14’1″ |
| MSD 4000 | 80,000 | 150,000 | 16,600 | 40 | 44 | 12’0″ |
| MSD 4000R | 100,000 | 170,000 | 19,000 | 40 | 44 | 14’11” |
| MSD 4500 | 90,000 | 160,000 | 17,900 | 38 | 43 | 10’8″ |
| MSD 4500R | 110,000 | 185,000 | 21,000 | 38 | 43 | 14’2″ |
| MSD 7500 | 135,000 | consult factory | 25,500 | 43 | 45 | 11’10” |
| MSD 7500R | 160,000 | 275,000 | 30,000 | 43 | 45 | 15’7″ |
| MSD 9500 | 175,000 | consult factory | 37,300 | 48 | 52 | 15’4″ |
| MSD 9500R | 275,000 | consult factory | 43,300 | 48 | 52 | 18’4″ |
