The V-Plow puts you in position for highly productive snow removal for your skid steer or Bobcat. V, scoop, left and right positions allow you maximum manoeuvrability and agile snowplough performance. position the blades where you need them for efficient snow removal with your skid steer. This attachment is engineered for quality from the ground up.
Features
- Two-way hydraulic only control provides full moldboard control in V, scoop, left and right positions
- 2” bore x 10” stroke cylinders with 1 1/4” rods and 1 1/4” cylinder pins
- Trip edge utilizing four extension springs
- Floating moldboard and adjustable cast skid shoes
- Central cutting edge bracket is designed to block snow from passing through the blade hinge point
| Model | 84” | 96” | 108” |
|---|---|---|---|
| Part Number | 900784 | 900785 | 900786 |
| Straight Blade Width | 86” | 98” | 110” |
| Angled Blade Width | 69” | 79” | 89” |
| V Position Width | 75” | 85” | 96” |
| Scoop Position Width | 63” | 73” | 81” |
| Blade Height | 31.8” | 31.8” | 31.8” |
| Blade Angle | +/- 36° | +/- 36° | +/- 36° |
| Amount of Float | +/- 2.5° | +/- 2.5° | +/- 2.5° |
| Overall Length | 41.75” | 41.75” | 41.75” |
| Moldboard Thickness | .135” | .135” | .135” |
| Bolt-on Cutting Edge | 1/2” x 6” | 1/2” x 6” | 1/2” x 6” |
| Approximate Weight | 840 lb. | 920 lb. | 1,000 lb. |
| Options | |||
| Hardened Skid Shoes | |||
| Factory Installed Couplers |
